Board Form Factor
UCFF (4inch x 4inch)
Internal Drive Form Factor
M.2 and 2.5inch Drive
Number of Internal Drives Supported
2
Lithography
14nm
TDP
15W
DC Input Voltage Supported
12V to 19V DC
Processor Included
Intel Core i3-5010U Processor (3M Cache, 2.10GHz)
Memory Specifications
Max Memory Size (Dependent on Memory Type): 16GB
Memory Type: DDR3L-1333/1600 1.35v 2xSO-DIMMs
Max Number of Memory Channels: 2
Max Memory Bandwidth: 25.6 GB/s
Max Number of DIMMs: 2
ECC Memory Supported: No
Graphics Specifications
Integrated Graphics: Yes
Graphics Output: mini-DP 1.2, mini-HDMI 1.4a
Intel Clear Video Technology: Yes
Number of Displayed Supported: 3
Expansion Options
PCI Express Revision: 2
PCI Express Configurations: M.2 Slot with PCIe x4 Lanes
Max Number of PCI Express Lanes: 4
PCIe x4 Gen 2.x: 1
I/O Specifications
USB Revision: USB 3.0, USB 2.0
Number of USB Ports: 6
USB 2.0 Configuration (Back Internal): 0 2
USB 3.0 Configuration (Back Internal): 2B, 2F 0
Total Number of SATA Ports: 2
Max Number of SATA 6.0 Gb/s Ports: 2
RAID Configuration: RAID 0, RAID 1
Audio (Back Channel Front Channel): 7.1 Digital Analog Stereo Headset
Integrated LAN: 10/100/100 Mbps
Integrated WiFi: Intel Wireless AC 7265 Bluetooth 4.0
Integrated Bluetooth: Yes
Package Contents
Intel NUC Kit NUC5i3RYH Integrated in Enclosure
VESA Mount Bracket, with Screws
19V 65W Wallmount AC-DC Power Adapter with Multi-Country AC Plugs (IEC Types A/C/G/I)
Integration Guide
Processor Badge
Item Dimension (L"xW"xH")
25.75 x 5.8 x 5.43
Weight
4.40 lb
Warranty Information
3 Years Limited
